GIGABYTE Z790 GAMING X AX 1.0 Motherboard

The GIGABYTE Z790 GAMING X AX (Rev. 1.0) is a performance-driven ATX motherboard built for Intel’s 12th and 13th Gen Core processors. It supports DDR5 memory, PCIe 5.0, and features integrated Wi-Fi 6E, making it ideal for gamers and creators looking for speed, reliability, and future-ready connectivity. With a robust power design, advanced cooling features, and multiple high-speed M.2 slots, this board offers a stable platform for demanding builds.
Technical Specifications
Socket: Intel LGA 1700
Chipset: Intel Z790
Form Factor: ATX
Memory Support:
4× DDR5 DIMM slots (up to 128GB)
Supports up to 7600MHz (OC)
Storage Support:
3× M.2 PCIe 4.0 x4 slots
6× SATA 6Gb/s ports
Expansion Slots:
1× PCIe 5.0 x16
2× PCIe 3.0 x16
Networking:
Wi-Fi 6E + Bluetooth 5.3
2.5GbE LAN (Realtek)
Audio: Realtek ALC897 HD Audio
USB Ports:
USB 3.2 Gen 2×2 Type-C
USB 3.2 Gen 2 / Gen 1
USB 2.0
BIOS: Q-Flash Plus
RGB: RGB Fusion 2.0 with ARGB/RGB headers
Cooling: Smart Fan 6
Power Design: 16+1+2 Twin Digital VRM with DrMOS
Key Features
Support for DDR5 up to 7600MHz OC
PCIe 5.0 x16 slot for latest GPUs
Wi-Fi 6E & 2.5GbE LAN for high-speed connectivity
Triple M.2 PCIe 4.0 slots for fast storage options
Q-Flash Plus for BIOS update without CPU or RAM
User Benefits
Optimized for high-performance gaming and workloads
Fast memory and storage support ensures smooth operation
Reliable thermal performance with Smart Fan 6
Expandable with multiple PCIe and M.2 slots
Modern connectivity with Wi-Fi 6E, Bluetooth 5.3, and USB-C
Compatibility
Supports Intel 12th and 13th Gen Core processors
Compatible with DDR5 memory
Fits standard ATX cases
Supports PCIe 5.0 GPUs and Gen4 NVMe SSDs
Included Items
GIGABYTE Z790 GAMING X AX Motherboard
Wi-Fi Antenna
SATA Cables
M.2 Screws
User Manual
Quick Installation Guide
