MSI PRO B650-P WIFI AMD B650 Socket AM5 ATX Motherboard

The MSI PRO B650-P WIFI is an ATX motherboard built for AMD Ryzen 7000 Series processors using the AM5 socket. It delivers stable performance, supports DDR5 memory, and offers modern connectivity features like PCIe 4.0, Wi-Fi 6E, and 2.5G LAN. Designed for business, productivity, and gaming builds, it includes extended heatsinks, digital power delivery, and clean layout for long-term reliability.
Technical Specifications
Chipset: AMD B650
Socket: AM5
CPU Support: AMD Ryzen 7000 Series
Memory Support:
DDR5 up to 6400+ MHz (OC)
4 x DIMM slots, up to 192GB
Expansion Slots:
1 x PCIe 4.0 x16
2 x PCIe 3.0 x1
Storage:
2 x M.2 (PCIe Gen 4)
4 x SATA 6Gb/s
Networking:
Intel Wi-Fi 6E
Realtek 2.5G LAN
Audio: Realtek ALC897 HD Audio
USB Ports:
Rear I/O: USB 3.2 Gen 2×2 Type-C, USB 3.2 Gen 2, USB 3.2 Gen 1, USB 2.0
Internal headers for front-panel USB
Cooling: Extended heatsinks, M.2 Shield Frozr, multiple fan headers
Form Factor: ATX
Key Features
Supports AMD Ryzen 7000 Series processors
DDR5 memory support up to 6400+ MHz (OC)
PCIe 4.0 x16 slot for high-speed GPUs
Dual M.2 Gen 4 slots for fast storage
Built-in Wi-Fi 6E and 2.5G LAN for fast networking
10+2+1 phase digital power design for stable delivery
User Benefits
Strong performance for gaming, rendering, and daily work
Fast, stable wired and wireless connectivity
Smooth multitasking and large memory capacity
Easy cable management with ATX layout
Good thermal stability under high loads
Compatibility
Works with AMD Ryzen 7000 Series (AM5 socket)
Supports Windows 10/11 (64-bit)
Supports DDR5 memory only
Fits ATX mid-tower and full-tower cases
Compatible with air and liquid cooling systems
Included Items
MSI PRO B650-P WIFI Motherboard
Wi-Fi antennas
SATA cables
I/O shield
User manual
